MONITOR CONVERSION
To convert a diffusion monitor to an aspirated monitor, only the Extended Range Li-ion or Alkaline battery packs are
approved for use.
To convert an aspirated monitor to a diffusion monitor, a suspender clip, washer, and screw are recommended for
use with the Li-ion battery pack. If attaching the Extended Range Li-ion or Alkaline battery packs, the conversion kit is
required.
NOTE: When an Extended Range Li-ion (or Alkaline) battery pack is attached to a diffusion monitor, the monitor’s lower portion becomes
deeper than its upper portion. The Conversion Kit’s suspender clip components are used to make the upper and lower portions depth-
compatible. The Conversion Kit provides a battery cover (battery not included), a suspender clip and spacer, and a screw and washer.
CONVERTING A DIFFUSION MONITOR TO AN ASPIR
A
TED MONITOR.
Removing the Suspender Clip and Battery Pack.
1 Power-off the monitor.
2 On the monitor’s case bottom (back of the monitor), open the suspender clip.
3 Using a Phillips head screwdriver, remove the screw and washer that attach the suspender clip (and
spacer, if applicable) to the monitor. Set aside and store any removed, unused items for future use with
a diffusion monitor.
4 Loosen the four captive screws on the lower portion of the case bottom. Lift and remove the battery
pack (and cover, if applicable). Set aside and store any removed, unused items for future use with a
diffusion monitor.
Assembling the Aspirated Monitor (including battery insertion).
If inserting the Alkaline battery pack, follow steps 1-10.
If inserting the Extended Range Li-ion battery pack, follow steps 5-10 ONLY.
1 To prepare the Alkaline battery pack, unlatch and lift the hinged portion of the battery pack.
2 If needed, remove and set aside any spent batteries from within the pack.
3 Insert new batteries so that their negative contacts are in contact with the springs inside the pack. DO
NOT MIX BATTERY TYPES.
4 Close the latch. A click sounds.
5 To properly place the Extended Range Li-ion (or Alkaline) battery pack inside the pump module,
complete or observe the following:
 the battery circuitry is exposed and faces the user;
 a small groove at the back of the battery bottom fits over the small rib at the back of the pump
module bottom.
6 Loosen the captive screw on the front of the pump module. Slide the module’s door down and lift to
open.
7 Place the monitor inside the pump module. The monitor is display side up and its logo readable. Its
lower exposed bottom portion covers the battery.
8 Tighten the four screws on the pump module bottom to secure the module to the monitor.
9 Close the pump door; slide up to click in place.
10 Tighten the pump door screw.
CONVERTING AN ASPIRATED MONITOR TO A DIFFUSION MONITOR.
Removing the Pump Module.
1 Power-off the monitor.
2 Loosen the four captive screws on the lower portion of the pump module bottom (back of the module).
3 Loosen the single captive screw on the pump module door.
4 Slide the pump door down; lift to reveal and access the monitor.
5 Lift and remove the monitor from the pump module; set aside and store for future use.
