Forecourt Controller Interface Installation Guide 25

August 11, 2016

5. Connect the power cable and one of the communications ribbon cables

to the current loop board. Connect the ribbon cables in the order shown.

6. Repeat steps 1 - 5 to connect additional current loop boards.

Board 1 Board 2 Board 3 Board 4

Power

Cable

Ribbon

Cable
