28 Forecourt Controller Interface Installation Guide

August 11, 2016

4. Connect the power cable and one of the ribbon cables to the current

loop board. Connect the ribbon cables in the order shown.

5. Repeat steps 1 - 4 to connect additional RS485 boards.

Board 1 Board 2 Board 3 Board 4

Power

Cable

Ribbon

Cable
