VX 820 DUET REFERENCE GUIDE 9
CHAPTER 1
Terminal Overview
This chapter provides a brief description of the VX 820 DUET.
VX 820 DUET
The VX 820 DUET is a complimentary solution for the VX 820. The VX 820 takes
the most usable and ergonomic hand-held PIN pad payment device and takes it to
a new level by adding a color touchscreen display, a larger keypad, and
integrated contactless capability. The addition of the VX 820 DUET, which
includes the base with the PIN pad, provides banking sector customers with a
competitively-priced high-end countertop solution. It also provides merchants with
a stable platform where they can place the PIN pad for handling PIN entry and
contactless activity.
Features at a
Glance
The following is a list of features of the VX 820 DUET:
Table 3 VX 820 DUET Features
Feature Description
Thermal Printer • Below 18 lines per second (LPS).
• Supports a 47mm wide by 25 meter long paper roll
• Out-of-Paper Sensor
• Double-height, double-width print and inverse printing
• Print column width option for 24/32/42 characters/line
• Supports existing PIN pad fonts
• Supports Eurocurrency symbol
• Supports up to ten user downloadable logos within a 16x16 to
240x384 size
• Supports 256 Kbytes of user downloadable fonts
Terminal Interface
Connector
• USB Host Port with a 5Vdc, 500mA power supply
• Supports powered 4-wire serial port
Communication • 56 Kbps Standard Dial-up Modem (Conexant ‘Harley’ chipset
solution) with RJ11 connector at the back of the base
• 10/100 Base T Ethernet with RJ45 connector at the back of
the base
Power • Supplied by an external universal-input power supply (9.3
VDC/4A)
Operating System • Verix eVo OS
Printer Firmware • New printer firmware developed based on STM MCU
STM32F103VCT6 plus Seiko thermal printer mechanism
LTPJ245G-S384-E.
