1: Overview
4 Verint Video Solutions
Casing Description
The S1900e electronics are enclosed in a non-weatherproof aluminum casing that is not
meant for outdoor use.
The front panel consists of:
A five-pole connector for the RS-422/485 serial port
A pair of 1/8 inch (3.5 mm) I/O audio connectors
One BNC connector for video input or output
The back panel consists of:
An SD card slot on the S1900e-AS and S1900e-AS-XT (for future use)
A system status LED
12V DC power poles
A reset button
One dry contact input and one relay output
An RJ-45 jack for the Ethernet network
RS-422/485 Video input or output
Audio input
Audio output
I/O RJ-45 EthernetReset
12V DC power
SD card slot on the S1900e-AS
and S1900e-AS-XT
System status
