Configuration and Operation
LD8 Operations Manual AB-V-MA-00635_RevA2 18
4.2.3 ENTERING A CUSTOM BEAM FREQUENCY
A custom L-band beam name and frequency (in Hz) can be manually entered, however this should be used
only under the instruction of VERIPOS support.
The format for assigning a user L-band beam is as follows:
ASSIGNLBANDBEAM MANUAL BEAMNAME FREQUENCY 1200
4.2.4 TRACKED L-BAND BEAM AND SIGNAL STRENGTH STATUS
The presently tracked L-band beam/s and signal strength/s can be found by entering:
The returned status will display information relating to any of the beams that are being actively tracked or
searched for.
The tracked L-band beam names will be found in quotation marks at the start of each line, i.e. “25E”. The value
after the beam name relates to the L-band beam frequency followed by the baud rate, which is typically 1200
bps. The signal strength will be found in the 8
th
field along for each beam line. Signal strengths are output in dB
and a value of 36.5dB or above is optimal.
When in auto beam mode the terminal output will be similar to the below:
LBANDTRACKSTAT WCOM1_30 0 50.5 FINESTEERING 2062 457753.000 0a000020 29e3 15441
3
"IOR" 1545865000 1200 974c 00c2 0 -91.416 43.052 3.6091 15658.910 298176 2330
746 38166528 290966 0.0000
"25E" 1545825000 1200 974c 00c2 0 -223.267 43.704 3.8057 78985.820 1504384 5 5
192561152 515 0.0000
"AORW" 1545845000 1200 974c 00c2 0 -280.645 40.858 2.8379 78986.523 1504448 607
571 192569344 68081 0.0015
