Verizon CE1000A - Extender Setup and Installation

SETTING UP YOUR
VERIZON WIFI EXTENDER
./ SETTING UP YOUR VERIZON WIFI EXTENDER
Note: Using a wired backhaul, the Verizon Wi-Fi Extender can be
placed at a location distant from the Verizon Router, and positioned
for optimum coverage. Using Wi-Fi backhaul, performance can
be slower and the distance from the Router will be determined by
the reach of Wi-Fi from the Verizon Router, the materials in the
home, and neighboring Wi-Fi trac. Wi-Fi backhaul is eective and
convenient for Wi-Fi configuration, but based on Wi-Fi interference
characteristics, does not perform as well as a wired connection.
2.0a/ WIRED INSTALLATION
A. Connect the Verizon Router to a coax outlet.
B. Connect the Verizon Wi-Fi Extender to a coax outlet -
ideally in an area with spotty Wi-Fi coverage.
C. Connect the power cords to the Router and Extender then
to an electrical outlet.
