7
Service Display States
Display Icon Status Description
No icons The display is o, and the LED
is also o.
The device is powered o or otherwise is not
getting power.
Network
signal
strength
An antenna with 0-4 bars. More bars indicate stronger signal.
Roaming
indicator
Present or not present. If the icon is present, the device is roaming on
another carrier’s network.
Battery
status
A battery outline lled with
bars; while charging, the bars
cycle from 0-4 bars. When
fully charged, the bars don’t
move.
When the battery is very
low, the battery outline
blinks on and o every two
seconds. Charge the battery
immediately.
More bars indicate more battery life.
Number of
Wi-Fi users
connected
Number of dots shown. The number of dots indicates the number of
Wi-Fi users connected to the device.
