Vermeiren Luna Basic 2 - 3 Installation and adjustment

Luna 2, Luna Basic 2, Luna UL 2
2016-06
Page18
Magnetic field for the
Supply frequency
(50/60 Hz) pursuant to
IEC 61000-4-8
3 A/m 3 A/m
Magnetic fields with the grid frequency
should comply to those normal in the
commercial or hospital environments.
NOTE VT is the grid alternating voltage before applying the test level.
3 Installation and adjustment
The instructions in this chapter are for the specialist dealer.
The Vermeiren Luna 2 has been designed to be adjust with a minimum of replacements
parts.
There is no need for extra stock of spare parts.
To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility.
A list of Vermeiren facilities can be found on the last page.
L WARNING: Risk of unsafe settings - Use only the settings described in this
manual.
3.1 Tools
To set up the bed no tools are needed.
3.2 Manner of delivery
The Vermeiren Luna 2 shall be delivered with:
 2 front parts incl. motors + wooden lagging Approx. 22,7 kg / piece
 Slatted frame, foot-end incl. motor Approx. 17,25 kg
 Slatted frame, head-end incl. transformer and motor Approx. 18,15 kg
 Side railings (2 x 2 wooden slats) Approx. 5,25 kg / piece
 Lifting pole + triangular grip Approx. 6,05 kg
 Handset Approx. 0,30 kg
 Instruction Manual
The Vermeiren Luna basic 2 shall be delivered with:
 2 front parts incl. motors + wooden lagging Approx. 15,5 kg / piece
 Slatted frame, foot-end incl. motor Approx. 17,25 kg
 Slatted frame, head-end incl. transformer and motor Approx. 18,15 kg
 Side railings (2 x 2 wooden slats) Approx. 5,25 kg / piece
 Lifting pole + triangular grip Approx. 6,05 kg
 Handset Approx. 0,30 kg
 Instruction Manual
The Vermeiren Luna UL 2 shall be delivered with:
 2 front parts incl. motors + wooden lagging Approx. 21,8 kg / piece
 Slatted frame, foot-end incl. motor Approx. 17,25 kg
 Slatted frame, head-end incl. transformer and motor Approx. 18,15 kg
 Side railings (2 x 2 wooden slats) Approx. 5,25 kg / piece
 Lifting pole + triangular grip Approx. 6,05 kg
 Handset Approx. 0,30 kg
 Instruction Manual
The nursing bed may only be used with the parts listed here. If parts are omitted or if foreign
furnishings, components or electrical systems are included, then this bed is not regarded as
a nursing bed supplied by the manufacturer, and you use it at your own risk. Then the CE
conformity and the warranty of the manufacturer do not apply.
