ermeirenplein 1/15, B-2920 Kalmthout
Type bed
Model Luna 2, Luna Basic 2, Luna UL 2
Maximum occupant mass 140 kg
Description Min. Max.
Length Luna 2, Luna Basic 2: 2170 mm; Luna UL 2: 2180 mm
Width Luna 2: 1020 mm; Luna Basic 2: 1015 mm; Luna UL 2: 1025 mm
Height (without lifting pole) Luna 2, Luna Basic 2: 840 mm - 1250 mm
Luna UL 2: 726 mm - 1136 mm
Height (with lifting pole) Luna 2, Luna Basic 2: 1675 mm - 2080 mm
Luna UL 2: 1590 mm - 1995 mm
Height adjustment of the bed
surface (position 1)
Luna 2, Luna Basic 2:
335 mm (without mattress)
Luna UL 2:
205 mm (without mattress)
Luna 2, Luna Basic 2:
745 mm (without mattress)
Luna UL 2:
615 mm (without mattress)
Height adjustment of the bed
surface (position 2)
400 mm (without mattress)
Not for Luna UL 2
810 mm (without mattress)
Not for Luna UL 2
Folded length 445 mm
Folded width 935 mm
Folded height 1045 mm
Total mass Luna 2: 98,15 kg; Luna Basic 2: 83,7 kg; Luna UL 2: 96,35 kg
Adjustment of the back section 83°
Max. thigh angle 31.7°
Max. angle for lower leg -14,8°
Max. safe load 175 kg
Lifting pole Nominal load 80 kg
Mattress Min. RG 35, thickness 120 mm, 2000 x 900 mm, max. 20 kg
Under clearance for patient lift 160 mm
Steering casters (4 pieces) Luna 2, Luna Basic 2: Ø 100 mm, can be locked
Luna UL 2: Ø 75 mm, can be locked
Front part of motor LA273100-A01405040, Linak
Back section motor LA270022-00, Linak
Leg section motor LA270022-00, Linak
Handset HBW074-072, Linak
Transformer CB6404+10019, Linak
Nominal voltage, transformer
U input: 230 V
, ± 10%, 50 Hz, current: max. 1.5 A, output voltage: 24V ,
max. 70 VA
Period switched on 10%, max. 6 min/hour
Noise level < 65 dB(A)
Class / Kind of protection Protection class II, application part Type B / IP54 (spray protection)
Storage and use temperature + 5 °C + 41 °C
Storage and use humidity 30% 70%
We reserve the right to introduce technical changes. Measurement tolerance ± 15 mm / 1,5 kg / °
Table 1: Technical specifications
