3.3.5 Transformer connections
L CAUTION: Risk of injury - Do not touch the plug with wet hands.
L CAUTION: Risk of injury - Do not place any objects on the connection and the
cable, and protect these against mechanical loads.
1. A 220 V / 230 V, 50 Hz power socket conforming to the VDE specifications is required
2. The diagram for the transformer connections is given in the figure below:
Take hold of the plug only to remove it from the power socket.
The power cable must be laid without any loops or kinks and should not pass around sharp
edges.
Protect the power cable and the cable leading to the handset from being crushed.
4 Maintenance
For the maintenance manual of the beds refer to the Vermeiren website:
www.vermeiren.com.
1 2 3 4
5
6
1 = Connection of panels motor
2 = Connection of knee-bending angle motor
3 = Connection of head-end motor
4 = Connection of foot-end motor
5 = Handset
6 = Transformer / control box
The cables of the motors and connections of the
transformers bear the same numbers.
1234
