Bollente trutankless® VERO Series Water Heaters www.trutankless.com
Ax the mounting brackets to the wall.
Brackets must be mounted to wall studs,
or with wall anchors appropriate for
the type of wall surface and sucient
to securely hold 40 pounds if there is no
conveniently located wood stud or other
structural member behind the surface.
Remove the cover from the unit and set it aside.
e VERO BR/BC unit has four (4) slots on the back panel that
t over corresponding hooks located on the top edge of each wall
bracket. One of the two brackets supplied with the trutankless unit
has two (2) truss head Philips machine screws lightly threaded into
it. Remove these two screws and carefully set aside.
Li the unit and center it over the brackets. Align the slots on the
back above the top line of the brackets, ush with the wall, and
lower the unit until the arcs of the hooks are fully resting in the
slots. Ensure that all 4 hooks are in place.
Line up the bottom screw holes with the corresponding holes on the lower bracket by sliding the unit le or right on the
brackets if necessary to center it, and then install the two (2) truss head screws, tightening with a Philips head screwdriver.
Figure 4 — Fastening the Unit
e trutankless unit is now securely axed to the wall.
