ELECTRICAL DATA
1
Voltage .......................................208 - 240 VAC
Phase .........................................SINGLE
Wattage .......................................12.5-36.0 kW
Max. amp, load ................................40A x 4 = 160A
Min. required circuit breaker size .................Depends on Model (See table below)
Required wire size AWG
2,3
.......................Depends on Model (See table below)
Model Height Width Depth Weight Amperage
Voltage
Range
KW Range
Main
Panel
Size
Breakers
(Two Pole)
[Optional]
Copper
Wire
[Optional]
Plumbing
Fittings
BR36 17 23.74˝ 5.5˝ 35.3 lbs 160 220 – 240 31.8 – 36.0 >200 A (2) 80 A (4) #4 AWG
Threaded
3/4” NPT
BR28 17˝ 23.74˝ 5.5˝ 35.3 lbs 120 220 – 240 26.4– 28.8 200 A
(1) 125 A
[(2) 60 A]
(2) #2 AWG
[(4) #6 AWG]
Threaded
3/4” NPT
BR24 17˝ 23.74˝ 5.5˝ 35.3 lbs 100 220 – 240 22.0 – 24.0 200 A
(1) 100 A
[(2) 50 A]
(2) #2 AWG
[(4) #6AWG]
Threaded
3/4” NPT
BR19 17˝ 23.74˝ 5.5˝ 35.3 lbs 80 220 – 240 17.6. – 19.2 150 A
(1) 80 A
[(2) 40 A]
(2) #4 AWG
[(4) #8 AWG]
Threaded
3/4” NPT
BR14 17˝ 23.74˝ 5.5˝ 35.3 lbs 60 220 – 240 13.2 – 14.4 125A
(1) 60 A
[(2) 30A]
(2) #6 AWG
[(4) #8 AWG]
Threaded
3/4” NPT
BC33 17˝ 23.74˝ 5.5˝ 35.9 lbs 160 208 33.3 >200 A (2) 80 A (4) #4 AWG
Threaded
3/4” NPT
BC25 17˝ 23.74˝ 5.5˝ 35.9 lbs 120 208 25.0 200 A
(1) 125 A
[(2) 60 A]
(2) #2 AWG
[(4) #6 AWG]
Threaded
3/4” NPT
BC20 17˝ 23.74˝ 5.5˝ 35.9 lbs 100 208 20.8 200 A
(1) 100 A
[(2) 50 A]
(2) #2 AWG
[(4) #6 AWG]
Threaded
3/4” NPT
BC16 17˝ 23.74˝ 5.5˝ 35.9 lbs 80 208 16.6 150 A
(1) 80 A
[(2) 40 A]
(2) #4 AWG
[(4) #8 AWG]
Threaded
3/4” NPT
BC12 17˝ 23.74˝ 5.5˝ 35.9 lbs 60 208 12.5 125A
(1) 60 A
[(2) 30A]
(2) #6 AWG
[(4) #8 AWG]
Threaded
3/4” NPT
THE ABOVE INFORMATION IS MEANT ONLY AS A GUIDELINE AND SHOULD NOT BE RELIED UPON
TO GUARANTEE SAFETY OF INSTALLATION OR CODE COMPLIANCE. ELECTRICAL WIRING SHOULD
ONLY BE PERFORMED BY A QUALIFIED AND PROPERLY LICENSED CONTRACTOR. PLEASE ENSURE
YOUR TRUTANKLESS VERO MODEL IS PROPERLY WIRED ACCORDING TO LOCAL AND NATIONAL
ELECTRICAL CODES. IMPROPER ELECTRICAL INSTALLATION COULD CAUSE DAMAGE TO PROPERTY
AND MAY RESULT IN PERSONAL INJURY OR DEATH.
1
NOTE: Tankless water heaters are considered a non-continuous load
2
NOTE: Conductors should be sized to maintain a voltage drop of less than 3% under load
3
American Wire Gauge (AWG) Tables are available at
http://en.wikipedia.org/wiki/American_wire_gauge#Tables_of_AWG_wire_sizes
