Bollente trutankless® VERO Series Water Heaters www.trutankless.com
PRODUCT MODEL AND SPECIFICATIONS
1. Pipe diameter: ¾ Inch (26mm)
2. Working Pressure: 145 psi
Table 1 — Product Specifications
ITEMS
RESIDENTIAL
SPECIFICATIONS
COMMERCIAL
SPECIFICATIONS
NOTES
Voltage Range 220V-240 VAC 50/60HZ 208 VAC 60HZ
Single-phase
Alternating Current
Current (Max. Load) 160 A
Power Capacity 13.2 – 36.0 KW 12.5 – 33.3 KW
Flow Rate
Min. 0.2 GPM (0.76 liters / min)
Max. 10 GPM (37.8 liters / min)
Max. Working Pressure 80 PSI (5.5 bar)
Max. Inlet Temperature 131°F (55 °C)
Outlet Temperature Range
90°F to 140°F
(32°C to 60°C)
90°F to 180°F
(32°C to 82.2°C)
Temperature Control Accuracy +/-1°C
Aer temperature
has stabilized
Over-temperature Protection >158°F (70°C) >198°F (92°C)
Over-voltage Protection >255 V >218 V
Leak Detection >.05 GPM
Short circuit Protection >63 A Each circuit breaker
Anti-freezing Mode
Engages at <41°F (5°C)
Disengages at >45°F (7°C)
