VX-110 OPERATING MANUAL30
Optional Cloning Cable "CT-27"
The VX-110 includes a convenient “Clone” feature, which allows the memory and con-
figuration data from one transceiver to be transferred to another VX-110. This can be
particularly useful when configuring a number of transceivers for a public service opera-
tion. Here is the procedure for Cloning one radio’s data to another:
Turn both radios off.
Connect the optional CT-27 cloning cable between the MIC/SP jacks of the two ra-
dios.
Press and hold the PTT and LAMP key while turning the radio on.
Rotate the DIAL to select “CLONE.”
Press the
[
F
]
key, to enter the CLONE mode. “CLONE” will appear on the displays of
both radios when the Clone mode is successfully activated in this step.
On the Destination radio, press the MONI key (“SAVING” will appear on the LCD).
Press the PTT key on the Source radio; “SENDING” will appear on the Source radio,
and the data is transferred.
If there is a problem during the cloning process, “C-ERROR” will be displayed. Check
your cable connections and battery voltage, and try again.
If the data transfer is successful, the Destination radio will return to normal operation;
Turn both radios off and disconnect the CT-27. You can then turn the radios back on,
and begin normal operation.
Cloning
