VX-4000 VHF Low-band Service Manual

MAIN Unit

REF.

DESCRIPTION VALUE WV TOL. VXSTD P/NMFR’S DESIG VERS.

LAY ADR.

LOT.SIDE.

C 1056 CHIP CAP. 0.5pF 50V CK GRM39CK0R5C50PT K22174201 1-7 B b2

C 1057 CHIP CAP. 0.001uF 25V CH GRM39CH102J25PT K22144204 1- B c5

C 1058 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-7 B b2

C 1059 CHIP CAP. 0.01uF 50V B GRM39B103J50PT K22174824 1- A E4

C 1060 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c5

C 1061 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1-7 B b2

C 1063 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A D1

C 1064 CHIP CAP. 4pF 50V CH GRM39CH040C50PT K22174205 1-3 A D5

C 1064 CHIP CAP. 4pF 50V CH GRM39CH040C50PT K22174205 VERSION A 4- A D5

C 1064 CHIP CAP. 3pF 50V CJ GRM39CJ030C50PT K22174204 VERSION B 4- A D5

C 1066 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-7 B b2

C 1068 CHIP CAP. 1uF 50V B GRM42-2B105K50PT K22175801 1- B a3

C 1069 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B d4

C 1070 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1-3 A E5

C 1070 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 VERSION A 4- A E5

C 1070 CHIP CAP. 3pF 50V CJ GRM39CJ030C50PT K22174204 VERSION B 4- A E5

C 1070 CHIP CAP. 5pF 50V CH GRM39CH050C50PT K22174206 VERSION B 17- A E5

C 1071 FILM CAP. 0.033uF 16V ECHU1C333JB5 K57120013 1- B c5

C 1072 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A D1

C 1073 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E2

C 1075 CHIP CAP. 27pF 50V CH GRM39CH270J50PT K22174221 1- A E5

C 1078 FILM CAP. 0.033uF 16V ECHU1C333JB5 K57120013 1- B c5

C 1079 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D1

C 1080 CHIP CAP. 33pF 50V CH GRM39CH330J50PT K22174223 1- A E5

C 1081 CHIP CAP. 33pF 50V CH GRM39CH330J50PT K22174223 1- A E5

C 1082 CHIP CAP. 68pF 50V CH GRM39CH680J50PT K22174231 1- A E4

C 1083 CHIP CAP. 68pF 50V CH GRM39CH680J50PT K22174231 1- A E5

C 1084 CHIP CAP. 39pF 50V CH GRM39CH390J50PT K22174225 1-3 A D1

C 1084 CHIP CAP. 39pF 50V CH GRM39CH390J50PT K22174225 VERSION A 4- A D1

C 1084 CHIP CAP. 33pF 50V CH GRM39CH330J50PT K22174223 VERSION A 8- A D1

C 1084 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 VERSION B 4- A D1

C 1086 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A D1

C 1087 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A E5

C 1088 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A G4

C 1089 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E4

C 1090 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E4

C 1092 CHIP CAP. 5pF 50V CH GRM39CH050C50PT K22174206 1- A E4

C 1093 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A E5

C 1094 CHIP CAP. 5pF 50V CH GRM39CH050C50PT K22174206 1- A E4

C 1095 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A A3

C 1096 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B c5

C 1097 CHIP CAP. 0.01uF 50V B GRM39B103J50PT K22174824 1- A E5

C 1098 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A A3

C 1099 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B c5

C 1100 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A G4

C 1101 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1-7 A F4

C 1101 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 VERSION A 8- A F4

C 1101 CHIP CAP. 0.001uF 630V R GHM1030R102K630PT K22281801 VERSION B 8- A F4

C 1102 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A G2

C 1103 CHIP CAP. 0.33uF 16V B GRM40B334K16PT K22120807 1- A E5

C 1105 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1-7 A F4

C 1105 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 VERSION A 8- A F4

C 1105 CHIP CAP. 0.001uF 630V R GHM1030R102K630PT K22281801 VERSION B 8- A F4

C 1106 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E4

C 1108 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B c4

C 1109 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A C1

C 1110 CHIP CAP. 0.01uF 50V B GRM39B103J50PT K22174824 1- A E4

C 1111 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A C1

C 1112 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A G5

C 1113 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b3
