VX-4000 VHF Low-band Service Manual
6C-3
KEY Unit
Parts List
*** KEY UNIT ***
PCB with Components CB1703001
Printed Circuit Board FR006070D 1-
C 3402 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B
D 3401 LED TLOU1008(T4) G2070796 1- A
D 3402 LED TLOU1008(T4) G2070796 1- A
D 3403 LED TLOU1008(T4) G2070796 1- A
D 3404 LED TLOU1008(T4) G2070796 1- A
D 3405 LED TLOU1008(T4) G2070796 1- A
J 3401 CONNECTOR 9110S-08 P1091014 1- B
MC3401 MIC. ELEMENT EM-140 M3290032 1- A
Q 3401 TRANSISTOR 2SA1602A-T11-1F G3116028F 1- B
R 3401 CHIP RES. 330k 1/16W 5% RMC1/16 334JATP J24185334 1- B
R 3402 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- B
R 3403 CHIP RES. 180 1/4W 5% RMC1/4 181JATP J24245181 1- B
R 3404 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B
R 3405 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B
R 3406 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1- B
R 3407 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- B
R 3408 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B
R 3409 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B
R 3410 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- B
R 3411 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- B
R 3412 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B
R 3413 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B
R 3414 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B
R 3420 CHIP RES. 220 1/4W 5% RMC1/4 221JATP J24245221 1- B
R 3421 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B
S 3401 TACT SWITCH SKQDAB N5090058 1- A
S 3402 TACT SWITCH SKQDAB N5090058 1- A
S 3403 TACT SWITCH SKQDAB N5090058 1- A
S 3404 TACT SWITCH SKQDAB N5090058 1- A
S 3405 TACT SWITCH SKQDAB N5090058 1- A
REF.
DESCRIPTION VALUE WV TOL. VXSTD P/NMFR’S DESIG VERS.
LAY ADR.
LOT.SIDE.
