Vertex Standard VX-4000L User Manual

VX-4000 VHF Low-band Service Manual
MIC CONN Unit
Circuit Diagram
Parts Layout
Side A Side B
Parts List
*** MIC CONN UNIT ***
PCB with Components CB1705001
Printed Circuit Board FR006090C 1-
C 3906 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B
C 3907 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B
C 3908 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B
J 3901 CONNECTOR 14FE-ST-VK-N P1091103 1- A
J 3902 CONNECTOR BM14B-SRSS-TBT P0091302 1- B
REF. DESCRIPTION
VALUE WV TOL. VXSTD P/NMFR’S DESIG VERS. LAY ADR.
LOT.SIDE.
