H-19

Parts List

RF Unit

C 1156 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B d7

C 1157 CHIP CAP. 68pF 50V CH GRM36CH680J50PT K22178232 1- B e7

C 1159 CHIP CAP. 120pF 50V CH GRM36CH121J50PT K22178238 1- B e7

C 1160 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c5

C 1161 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B f3

C 1162 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B d7

C 1163 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c5

C 1164 CHIP CAP. 18pF 50V CH GRM36CH180J50PT K22178218 1- B d5

C 1165 CHIP CAP. 680pF 50V B GRM36B681K50PT K22178807 1- B d7

C 1166 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B f3

C 1167 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B d3

C 1168 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B d7

C 1169 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F6

C 1170 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A D5

C 1171 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B f3

C 1172 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F6

C 1173 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- B d6

C 1175 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B e6

C 1176 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B e7

C 1177 CHIP CAP. 68pF 50V CH GRM36CH680J50PT K22178232 1- B b6

C 1178 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c5

C 1179 CHIP CAP. 12pF 50V CH GRM36CH120J50PT K22178214 1- B d5

C 1180 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- A F7

C 1181 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 1- B d5

C 1182 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c5

C 1183 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B e3

C 1184 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F6

C 1185 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B b6

C 1186 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- B d3

C 1187 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- B d7

C 1188 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- B b5

C 1189 CHIP CAP. 330pF 50V B GRM36B331K50PT K22178803 1- A G6

C 1190 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B h5

C 1191 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F6

C 1192 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B e3

C 1193 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B e3

C 1194 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b5

C 1195 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B e3

C 1196 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B e4

C 1197 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b6

C 1198 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B d6

C 1199 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B h5

C 1201 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F7

C 1202 CHIP CAP. 12pF 50V CH GRM36CH120J50PT K22178214 1- B e4

C 1203 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- A G6

C 1204 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c5

C 1207 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B e4

C 1208 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F7

C 1209 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- B b5

C 1210 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b5

C 1211 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b6

C 1212 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B e4

C 1213 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e5

C 1216 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A F7

C 1217 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b5

C 1218 CHIP CAP. 0.5pF 50V CK GRM36CK0R5B50PT K22178285 1- B e5

C 1219 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B f7

C 1220 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d4

C 1221 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B e5

C 1222 CHIP CAP. 1pF 50V CK GRM36CK010B50PT K22178287 1- B e5

C 1223 CHIP CAP. 9pF 50V CH GRM36CH090D50PT K22178211 1- B a5

C 1224 CHIP CAP. 1.5pF 50V CK GRM36CK1R5B50PT K22178288 1- B e5

C 1225 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B d4

C 1226 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B e5

C 1227 CHIP CAP. 18pF 50V CH GRM36CH180J50PT K22178218 1- B e5

C 1227 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 4- B e5

C 1228 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A G7

C 1229 CHIP CAP. 1uF 10V B GRM40B105K10PT K22100802 1- A F7

C 1231 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B d5

C 1232 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d5

C 1233 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b6

C 1234 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B e5

C 1235 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c6

C 1236 CHIP CAP. 27pF 50V CH GRM36CH270J50PT K22178222 1- B a5

C 1237 CHIP CAP. 56pF 50V CH GRM36CH560J50PT K22178230 1- B e5

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.
