H-20

Parts List

RF Unit

C 1237 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 4- B e5

C 1238 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B e5

C 1239 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B e5

C 1240 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e5

C 1241 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A D5

C 1242 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a5

C 1244 CHIP CAP. 12pF 50V CH GRM36CH120J50PT K22178214 1- B b7

C 1245 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c7

C 1246 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- A D5

C 1248 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B e5

C 1249 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B h5

C 1251 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B e4

C 1252 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1- B b7

C 1253 CHIP CAP. 27pF 50V CH GRM36CH270J50PT K22178222 1- B b7

C 1254 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a6

C 1255 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A D4

C 1257 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B e4

C 1259 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C6

C 1260 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e5

C 1261 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C3

C 1262 CHIP CAP. 5pF 50V CH GRM36CH050C50PT K22178207 1- B b7

C 1263 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- A D3

C 1264 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D6

C 1265 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a6

C 1266 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B e4

C 1267 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B d5

C 1268 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B e5

C 1269 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B b7

C 1270 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A G7

C 1271 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C6

C 1272 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A D5

C 1273 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g4

C 1274 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B e4

C 1275 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b7

C 1276 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b6

C 1277 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a6

C 1278 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d5

C 1279 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g4

C 1280 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 1- B b7

C 1281 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C6

C 1282 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E4

C 1283 CHIP CAP. 0.033uF 10V B GRM36B333K10PT K22108803 1- A F5

C 1284 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d5

C 1285 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A B7

C 1286 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C7

C 1287 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J6

C 1288 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A J5

C 1289 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J5

C 1290 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D4

C 1291 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A B6

C 1293 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A D4

C 1294 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A B6

C 1295 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- A D4

C 1296 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c7

C 1297 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c7

C 1298 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- B c6

C 1299 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1300 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D4

C 1301 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- A I6

C 1302 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A J6

C 1303 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A H6

C 1304 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- A J6

C 1305 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c6

C 1306 CHIP TA.CAP. 0.68uF 20V TESVA1D684M1-8R K78130009 1- B d6

C 1307 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A5

C 1308 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J6

C 1309 CHIP CAP. 82pF 50V CH GRM36CH820J50PT K22178234 1- A J6

C 1310 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c7

C 1311 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J6

C 1312 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c7

C 1313 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d7

C 1314 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c6

C 1315 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c6

C 1316 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B j1

C 1317 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A I7

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR
