Vertex Standard VX-4200 Series Service Manual

H-24
Parts List
RF Unit
Q 1021 IC LA8630M-B-TE-R G1093452 1- B g6
Q 1022 TRANSISTOR 2SC3357-T2 RF G3333577F 1- B c4
Q 1023 TRANSISTOR DTC144EE TL G3070075 1- B h6
Q 1024 TRANSISTOR DTC144EE TL G3070075 1- B g5
Q 1025 TRANSISTOR 2SC4617 TL R G3346178R 1- B i6
Q 1026 TRANSISTOR 2SC4617 TL R G3346178R 1- B j5
Q 1027 TRANSISTOR 2SC4617 TL R G3346178R 1- B i5
Q 1028 IC S-AV32(VX) G1093916 1-7 A D1
Q 1028 IC RA30H1317M-01 G1093639 25W 8- A D1
Q 1028 IC S-AV32(VX) G1093916 50W 8- A D1
Q 1029 IC M62364FP 600D G1093033 1- A E7
Q 1030 TRANSISTOR DTC144EE TL G3070075 1- B i5
Q 1031 TRANSISTOR DTA124EE TL G3070116 1- B i5
Q 1032 TRANSISTOR DTC144EE TL G3070075 1- B g6
Q 1033 TRANSISTOR DTC144EE TL G3070075 1- A H3
Q 1034 IC BD6111FV-E2 G1093746 1- B f3
Q 1035 IC SPM5001 G1093686 1- B c6
Q 1036 IC NJM2125F(TAPE) G1093894 1- B f3
Q 1037 IC AK2345(TAPE) G1093184 1- B e7
Q 1038 TRANSISTOR 2SC5226-4-TL G3352268D 1- B d3
Q 1039 TRANSISTOR UMC5N TR G3070137 1- A F4
Q 1044 TRANSISTOR 2SA1774 TL R G3117748R 1- B e3
Q 1045 TRANSISTOR DTC114TE TL G3070225 1- B h5
Q 1046 TRANSISTOR 2SC3357-T2 RF G3333577F 1- B b5
Q 1047 TRANSISTOR DTC144EE TL G3070075 1- B e5
Q 1049 TRANSISTOR 2SC5226-4-TL G3352268D 1- B e4
Q 1051 TRANSISTOR DTC144EE TL G3070075 1- A C5
Q 1053 TRANSISTOR DTC144EE TL G3070075 1- B e5
Q 1054 FET 2SK508-T2B K52 G3805087B 1- B e5
Q 1055 TRANSISTOR DTC144EE TL G3070075 1- B b6
Q 1056 TRANSISTOR DTC114TE TL G3070225 1- B d4
Q 1057 TRANSISTOR 2SC5226-4-TL G3352268D 1- B c6
Q 1058 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- B e5
Q 1059 TRANSISTOR 2SC5226-4-TL G3352268D 1- B a5
Q 1060 IC TK71735SCL G1093835 1 A D5
Q 1060 IC TAR5S35(TE85L) G1093939 2- A D5
Q 1061 TRANSISTOR XN1501-(TX) G3070149 1- B g4
Q 1062 TRANSISTOR 2SB1201S-TL G3070195 1- B g4
Q 1063 IC BU4066BCFV-E2 G1093537 1- A D6
Q 1063 IC CD4066BPWR G1093865 6- A D6
Q 1064 IC LC73881M-TLM G1092755 1- B h6
Q 1065 IC S-80835CNMC-B8U-T2 G1093606 1- A C6
Q 1066 IC NJM12902V(TE1) G1093592 1- A C4
Q 1067 TRANSISTOR 2SC4617 TL R G3346178R 1- B e4
Q 1068 IC BU4066BCFV-E2 G1093537 1- A C5
Q 1068 IC CD4066BPWR G1093865 6- A C5
Q 1069 IC TAR5S50(TE85L) G1093914 1- A D4
Q 1070 TRANSISTOR DTC144EE TL G3070075 1- A J5
Q 1071 TRANSISTOR DTC144EE TL G3070075 1- A A2
Q 1071 FET 3LN01S-TL G3070330 8- A A2
Q 1072 TRANSISTOR 2SC4617 TL R G3346178R 1- A C6
Q 1073 TRANSISTOR DTC144EE TL G3070075 1- A A2
Q 1074 IC NJM12902V(TE1) G1093592 1- A F6
Q 1075 TRANSISTOR DTC114TE TL G3070225 1- A C7
Q 1076 IC NJM12902V(TE1) G1093592 1- A G7
Q 1077 TRANSISTOR DTC144EE TL G3070075 1- A A1
Q 1077 FET 3LN01S-TL G3070330 8- A A1
Q 1078 FET 2SK880GR TE85R G3808807G 1- B c6
Q 1079 IC TA31136FN(EL) G1091605 1- A J6
Q 1080 IC BR93L66RFVM-WTR G1093874 1- A A6
Q 1081 TRANSISTOR DTC144EE TL G3070075 1- A A1
Q 1082 TRANSISTOR DTC144EE TL G3070075 1- A B2
Q 1082 FET 3LN01S-TL G3070330 8- A B2
Q 1083 IC LC87F74C8A-TQFP-E
 1- A B5
Q 1084 TRANSISTOR DTC144EE TL G3070075 1- A B2
Q 1085 IC SA7025DK G1093014 1- B c7
Q 1086 TRANSISTOR DTC144EE TL G3070075 1- A B2
Q 1086 FET 3LN01S-TL G3070330 8- A B2
Q 1087 TRANSISTOR DTC144EE TL G3070075 1- A A2
Q 1088 IC NJM12902V(TE1) G1093592 1- B f7
Q 1089 IC NJM12902V(TE1) G1093592 1- A F7
Q 1090 IC NJM12902V(TE1) G1093592 1- A H3
Q 1091 TRANSISTOR 2SC4617 TL R G3346178R 1- A I6
Q 1092 TRANSISTOR DTC144EE TL G3070075 1- A J7
Q 1093 TRANSISTOR DTC144EE TL G3070075 1- A J7

:
Please contact Vertex Standard
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
