Vertex Standard VX-4200 Series Service Manual

H-25
Parts List
RF Unit
Q 1094 TRANSISTOR DTC144EE TL G3070075 1- A A2
R 1001 CHIP RES. 68 1/16W 5% RMC1/16S 680JTH J24189011 1- B e3
R 1002 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e3
R 1003 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1- B e3
R 1004 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C5
R 1005 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B j3
R 1006 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C4
R 1007 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C3
R 1008 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C4
R 1009 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- A C4
R 1010 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A G3
R 1011 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F4
R 1011 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 3- A F4
R 1012 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F4
R 1013 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- A C5
R 1014 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- A C5
R 1015 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A I5
R 1017 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B j4
R 1018 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B j4
R 1019 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A C5
R 1020 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A I5
R 1021 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1-2
R 1022 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- A D6
R 1023 CHIP RES. 100 1W 5% RMC1 101JTE J24305101 1- A G3
R 1024 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A F4
R 1025 CHIP RES. 100 1/4W 5% RMC1/4 101JATP J24245101 1- B b3
R 1026 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A C6
R 1027 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A I5
R 1028 CHIP RES. 18k 1/16W 5% RMC1/16S 183JTH J24189040 1- A C6
R 1029 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A F4
R 1031 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C5
R 1032 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B g6
R 1033 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c3
R 1034 CHIP RES. 100 1/4W 5% RMC1/4 101JATP J24245101 1- B c3
R 1035 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1-7 B c3
R 1035 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 25W 8- B c3
R 1035 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 50W 8- B c3
R 1036 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A H4
R 1037 CHIP RES. 18k 1/16W 5% RMC1/16S 183JTH J24189040 1- A H4
R 1038 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D6
R 1039 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c3
R 1040 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c4
R 1041 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B i5
R 1042 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D6
R 1043 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A H3
R 1044 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B j5
R 1045 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c3
R 1047 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c4
R 1048 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A H3
R 1049 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A H3
R 1050 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B j5
R 1051 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B c4
R 1052 CHIP RES. 18k 1/16W 5% RMC1/16S 183JTH J24189040 1- A C5
R 1053 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- A C5
R 1054 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1-7 B c3
R 1054 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 25W 8- B c3
R 1054 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 50W 8- B c3
R 1055 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B g6
R 1056 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B f6
R 1057 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B f7
R 1058 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B g5
R 1060 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B g4
R 1061 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B h6
R 1062 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A H4
R 1064 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B c4
R 1066 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- A H3
R 1067 CHIP RES. 560k 1/16W 5% RMC1/16S 564JTH J24189058 1- B f6
R 1068 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B g5
R 1069 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B g4
R 1070 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B f7
R 1071 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- B f7
R 1072 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A I3
R 1073 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- A I3
R 1074 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B f6
R 1075 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A I3
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
