Vertex Standard VX-4200 Series Service Manual

H-27
Parts List
RF Unit
R 1157 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B e6
R 1158 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B d6
R 1159 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A G6
R 1160 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B d6
R 1161 CHIP RES. 18 1/16W 5% RMC1/16S 180JTH J24189004 1- B e3
R 1162 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A F6
R 1163 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B d6
R 1164 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B h5
R 1165 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c5
R 1166 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G6
R 1167 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A G6
R 1168 CHIP RES. 560k 1/16W 5% RMC1/16S 564JTH J24189058 1- A F6
R 1169 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- B b6
R 1170 CHIP RES. 560k 1/16W 5% RMC1/16S 564JTH J24189058 1- A F7
R 1171 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B b6
R 1173 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e5
R 1174 CHIP RES. 560k 1/16W 5% RMC1/16S 564JTH J24189058 1- A F7
R 1176 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e4
R 1177 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e4
R 1178 CHIP RES. 560 1/16W 5% RMC1/16S 561JTH J24189022 1- B e4
R 1180 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G7
R 1181 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A F7
R 1182 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b5
R 1183 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e4
R 1184 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A F4
R 1186 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A F7
R 1187 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A F7
R 1188 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D5
R 1189 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D5
R 1190 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B e5
R 1191 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B e4
R 1192 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D5
R 1193 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D4
R 1194 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D5
R 1196 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D5
R 1197 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D5
R 1198 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B c6
R 1199 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A G7
R 1200 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B d5
R 1201 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B a5
R 1202 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e5
R 1203 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b6
R 1204 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a5
R 1206 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B e5
R 1207 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- B e5
R 1208 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A G7
R 1210 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B g4
R 1211 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- B g5
R 1212 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1- B a5
R 1213 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B g4
R 1214 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A C3
R 1215 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- A F7
R 1216 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A G7
R 1217 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A G7
R 1218 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g4
R 1219 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A C6
R 1220 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C6
R 1221 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A F7
R 1222 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A C3
R 1223 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B g4
R 1224 CHIP RES. 270 1/16W 5% RMC1/16S 271JTH J24189018 1- B a6
R 1225 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B a6
R 1226 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C6
R 1227 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A C6
R 1228 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e4
R 1229 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B g4
R 1230 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A C6
R 1231 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A J6
R 1232 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A C6
R 1233 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b7
R 1234 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B6
R 1235 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A2
R 1236 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B6
R 1236 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 4- A B6
R 1237 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a6
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
