Vertex Standard VX-4200 Series Service Manual

H-28
Parts List
RF Unit
R 1238 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B h5
R 1239 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B a6
R 1240 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c7
R 1241 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A C7
R 1242 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c6
R 1243 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B6
R 1244 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B6
R 1245 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A J6
R 1247 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c6
R 1248 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A6
R 1249 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A H6
R 1250 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A1
R 1251 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c7
R 1252 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A6
R 1253 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c6
R 1254 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1- B c6
R 1255 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c7
R 1256 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c6
R 1258 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B c6
R 1259 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- A I7
R 1260 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B a6
R 1261 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A6
R 1262 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1263 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A A6
R 1264 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1265 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1266 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1267 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1268 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1269 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1270 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1271 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1272 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1273 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1274 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1275 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1276 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1277 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1278 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1279 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1280 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B6
R 1281 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B2
R 1282 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B d7
R 1283 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B d6
R 1284 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- A I6
R 1285 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c6
R 1286 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- A I6
R 1287 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A6
R 1288 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A J7
R 1289 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c6
R 1290 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A A6
R 1291 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1292 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1293 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A6
R 1294 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1295 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- A I7
R 1296 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A6
R 1297 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1298 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A J6
R 1299 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A6
R 1300 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1301 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A I6
R 1302 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1-3 A A2
R 1303 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- A H6
R 1304 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B c7
R 1305 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A6
R 1306 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1307 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A J6
R 1309 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1310 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- A H7
R 1311 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c7
R 1312 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A J6
R 1314 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1315 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- A I6
R 1316 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c7
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
