Vertex Standard VX-4200 Series Service Manual

H-29
Parts List
RF Unit
R 1318 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1321 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C6
R 1322 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1323 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A C5
R 1324 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A I6
R 1325 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- A I7
R 1326 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c7
R 1327 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1328 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- A C5
R 1329 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- A G7
R 1330 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1331 CHIP RES. 20k 1/16W 0.5% RR0510R-203-D J24189150 1- A C5
R 1332 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A I7
R 1333 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A I6
R 1334 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C5
R 1335 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c7
R 1336 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1337 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A H7
R 1338 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1339 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A J7
R 1340 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1341 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1342 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A I6
R 1343 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 6- A A5
R 1344 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1345 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A H7
R 1346 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1347 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1348 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A2
R 1350 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1351 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1352 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f7
R 1353 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1354 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1355 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C4
R 1356 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C4
R 1357 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A I7
R 1358 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f7
R 1359 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B f7
R 1360 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1361 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1362 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f7
R 1363 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1364 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1365 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1366 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1367 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- B g7
R 1368 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A I7
R 1369 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1370 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1371 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B f7
R 1372 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C4
R 1373 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A I7
R 1374 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A5
R 1375 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C5
R 1376 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 1377 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B f6
R 1378 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f7
R 1379 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A I7
R 1380 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1381 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1382 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B4
R 1383 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1384 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1389 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 3- A B5
R 1390 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 3- A B4
R 1391 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1392 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1393 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 3- A B4
R 1394 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 3- A B5
R 1395 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1396 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B4
R 1397 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1398 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1399 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR

Vertex Standard VX-4200 Series Specifications

General

Brand	Vertex Standard
Model	VX-4200 Series
Category	Transceiver
Language	English
