Vertex Standard VX-4200 Series Service Manual

H-30
Parts List
RF Unit
R 1400 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B5
R 1401 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- A A3
R 1402 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b7
R 1403 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A F4
R 1404 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b3
R 1405 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B c3
R 1406 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1 B h5
R 1407 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1408 CHIP RES. 560 1/10W 5% RMC1/10T 561J J24205561 1- B i1
R 1409 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1410 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1411 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1412 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1413 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1414 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1415 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1416 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B i1
R 1417 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A B2
R 1418 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A B2
R 1419 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A B2
R 1420 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D6
R 1421 CHIP RES. 18 1/16W 5% RMC1/16S 180JTH J24189004 1- B e3
R 1422 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B e3
R 1423 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B e3
R 1424 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A I3
R 1425 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A E7
R 1427 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A H4
R 1428 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A H4
R 1429 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A H4
R 1430 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A H4
R 1431 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A H4
R 1432 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A H4
R 1433 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D3
R 1434 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b5
R 1435 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C5
R 1436 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C5
R 1437 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C5
R 1438 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A E6
R 1439 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B e6
R 1440 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1 A B2
R 1440 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 2- A B2
R 1441 CHIP RES. 22k 1/10W 5% RMC1/10T 223J J24205223 1 A B2
R 1441 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 2- A B2
R 1442 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 2- B g5
R 1443 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 2- B g3
R 1444 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1-2
T 1001 COIL 07RF P600ENAS-10733AQ L0022837 1- B a4
T 1002 COIL 07RF P600ENAS-10734IB L0022838 1- B b4
T 1003 COIL 07RF P600ENAS-10735AQ L0022839 1- B b4
T 1004 BALUN TRANSFOMERS B5F458DB-1414=P3 L0190256 1- B c5
T 1005 BALUN TRANSFOMERS B5F458DB-1414=P3 L0190256 1- B d6
T 1006 BALUN TRANSFOMERS B5F458PT-1417=P3 L0190258 1- B c6
T 1007 BALUN TRANSFOMERS B5F458DB-1542=P3 L0190266 1- B b5
TH1001 THERMISTOR ERTJ0EV473J G9090120 1- B d2
X 1001 XTAL U3B 4.194304MHz 4.194304MHZ H0103284 1- B h5
X 1002 XTAL U3B 7.3728MHz 7.3728MHZ H0103280 1- A B7
X 1003 XTAL OSC 16.8MHz TTS05VS-P2 16.8MHZ H9500760 1- A H7
XF1001 XTAL FILTER MFT50.85P 50.85MHZ H1102361 1- B a5
SHIELD CASE VCO RA0488600 1-
SHIELD PLATE PA R0124501 1-
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
