36VX-4500/-4600 Series VHF FM Transceiver Service Manual
PCB with Components CB5426001 CH:8
Printed Circuit Board FR021710B 1-2
FR021710C 3
FR021710D 4-
FRONT PANEL ASSY (8CH) RA124940A
PACKING PAD (PANEL) RA1234400
RUBBER KNOB RA124700A
VOLUME KNOB RA1245900
SPEAKER 20- 5015134H02 M4090203
SP HOLDER RA1261500
HOLDER (LED) RA124680A
LIGHT GUIDE (LED) RA1246900
SHEET (LED) RA1254600
LED FILTER (8CH) RA0997300
J 2004 LEAF SPRING RA1296700 1-2 B e1
J 2004 LEAF SPRING RA129670B 3 B e1
J 2004 LEAF SPRING RA129670C 4- B e1
J 2005 LEAF SPRING RA1296700 1-2 B a1
J 2005 LEAF SPRING RA129670B 3 B a1
J 2005 LEAF SPRING RA129670C 4- B a1
VR2001 POT. RK09L1140 20KB J60800308 1-3 A B1
VR2001 POT. RK09L1140C33 20KB J60800312 4- A B1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
Parts List
FRONT-A Unit
