43VX-4500/-4600 Series VHF FM Transceiver Service Manual
PCB with Components CB5427001 CH:512
Printed Circuit Board FR021720B 1-2
FR021720C 3
FR021720D 4-
FRONT PANEL ASSY RA124930A
PACKING PAD (PANEL) RA1234400
RUBBER KNOB RA124700A
VOLUME KNOB RA1245900
LCD HOLDER RA1244600
LIGHT GUIDE (LCD) RA124470A
REFLECTOR SHEET (093) RA1288200
INTER CONNECTOR RA1244800
SPONGE RUBBER (LCD) RA0786900
REFLECTOR SHEET (SUB) RA1292600
SPEAKER 20- 5015134H02 M4090203
SP HOLDER RA1261500
DS3001 LCD GS-35720-TFZWU G6090201 A C1
J 3004 LEAF SPRING RA1296700 1-2 B e1
J 3004 LEAF SPRING RA129670B 3 B e1
J 3004 LEAF SPRING RA129670C 4- B e1
J 3005 LEAF SPRING RA1296700 1-2 B a1
J 3005 LEAF SPRING RA129670B 3 B a1
J 3005 LEAF SPRING RA129670C 4- B a1
Q 3001 TRANSISTOR 2SB1132 T100 R G3211327R B c1
Q 3003 IC HA178L09UA-TL-E G1094350 B d2
TH3001 THERMISTOR ERTJ0EV473J G9090120 B c1
VR3001 POT. RK09L1140 20KB J60800308 1-2 A B1
VR3001 POT. RK09L1140C33 20KB J60800312 3- A B1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
Parts List
FRONT-B Unit
