Table 4: Mini Control Unit Basic Settings Menu Navigation
Parameter Menu Navigation
Date Main Menu / Settings / Sys Settings / Date.
Time
Main Menu / Settings / Sys Settings / Time.
IP Communications
Parameters
(IP address, subnet mask
address, gateway address)
Main Menu / Settings / Communication / enter parameters.
Float Voltage Main Menu / Settings / Batt Settings / Float Voltage.
Equalize Voltage
Main Menu / Settings / Batt Settings / EQ Voltage.
Battery Current Limit
Main Menu / Settings / Batt Settings / Curr Limit Mode (set to yes)
and Batt Curr Limit.
Battery Capacity Main Menu / Settings / Batt1 Setting or Batt2 Setting / Rated Capacity.
Reset Battery Capacity
Main Menu / Settings / Batt Settings / Reset Batt Cap
BTRM Feature
Web Menu Navigation Only: Settings Menu / Battery Tab.
Battery Charge Temperature
Compensation
Main Menu / Settings / Batt Settings / (enter parameters).
HVSD Limit
Web Menu Navigation Only: Settings Menu / Rectifiers Tab / HVSD
(set to enabled) then set HVSD Limit.
Rectifier Current Limit
Main Menu / Settings / Rect Settings / Current Limit (set to enabled)
then set Curr Limit Pt.
Over Voltage Alarm 1 Main Menu / Settings / Other Setting / Over Voltage 1.
Over Voltage Alarm 2
Main Menu / Settings / Other Setting / Over Voltage 2.
Under Voltage Alarm 1 Main Menu / Settings / Other Setting / Under Voltage 1.
Under Voltage Alarm 2
Main Menu / Settings / Other Setting / Under Voltage 2.
Changing Battery Capacity Rating in the Mini Control Unit
NOTE! After setting the battery capacity, the User should also reset the battery capacity (battery must
be fully charged).
1. Change the battery capacity setting of the Mini Control Unit to match the battery connected to the
power system.
Local Menu Navigation:
Main Menu / Settings / Batt1 Setting or Batt2 Setting / Rated Capacity.
Web Menu Navigation:
Settings Menu / Battery Tab / Batt1 Rated Capacity and Batt2 Rated Capacity.
2. Reset the battery capacity (resets the battery capacity calculation).
