Vertiv | NetSure™ 2100 Series -48 VDC Power System Installation Manual (IM582138000) | Rev. C
Securing the System to a Wall with Wall Bracket Kit P/N 541285 (if furnished)
An optional wall mount bracket kit (P/N 541285) is available for horizontal or vertical wall mounting of the
system.
NOTE!
Refer to “General Requirements” on page 13 for mounting restrictions and ventilation
requirements.
Procedure
1. The installer must provide fasteners for securing the system to a wall or other vertical surface. Ensure
that the wall and fastening technique are suitable for supporting the weight of the system. Refer to
System Application Guide SAG582138000 for system weight and additional dimensions.
2. Select either the vertical-mount or horizontal-mount brackets as required for your application. Attach
the brackets to the system mounting angles using kit-furnished screws. Torque to 60 in-lbs. Refer to
Figure 4 or Figure 5.
3. Using the drill guide dimensions in Figure 4 or Figure 5, prepare the wall for customer-furnished
fasteners. Secure the system to the wall.
