Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
4
Figure 2.1 NetSure™ SM-DU+ Assembly Switch Locations
SW1
SW2
on
5678
1234
off
on
5678
1234
off
PowerCANRS485RS485
RS232
SW1SW2
J1
J7
ShuntShunt
J8J6
Fuse
J3
J4J4A
J5
ON
OFF
Green Indicator
8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1
SM-DU+ Circuit Board
Note that these ports are not used in this application,
refer to below image for customer connections
terminal blocks location. See also Figure 4.2.
Switch SW2
Switch SW1
Note that these terminal
blocks are for customer
connections. See also
Figure 4.2.
