Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
2 Switch Settings
2.1 General
The Vertiv™ NetSure™ SM-DU+ assembly uses two (2) 8-bit switches for parameter settings (SW1 and SW2). Refer to Figure 2.1 for
SW1 and SW2 locations. Refer to Table 2.1 for SW1 and SW2 settings.
Perform the following procedure to make switch setting adjustments.
Procedure
1. Remove the top cover to access the switches.
2. Set SW1 and SW2 per site requirements. Refer to Figure 2.1 for location. See Table 2.1 for setting descriptions. (Set the
addressing switches on each NetSure™ SM-DU+ assembly installed in the system to a unique address per Table 2.1.)
