A Parts List
A.1 VESDA VLP
Part
number
Description
VSP-000 Blank plate, non-EMC painted, with VESDA logo
VSP-001 Programmer Module
VSP-002 Display Module
VSP-005 Filter Cartridge
VSP-006 VESDA VLP Detector Chassis Assembly complete with Manifold
l VSP-006: EN 54-20 compliant
l VSP-006-NEN: Non-EN 54-20 compliant
Note: Refer to Section 8.1.3 for further information.
VSP-013 Detector Cover Assembly complete with EMC shields
VSP-014 7-relay Head Termination Card (HTC7)
VSP-015 VESDA VLP Detector Aspirator Assembly
VSP-019 Filter Cover
VSP-021 Imperial Pipe Adaptors (25 mm to 27 mm) (4 off) (US only)
VSP-100 Blank plate with FIRE 1 & OK LEDs, non-EMC painted, with VESDA logo
VSP-101 Blank plate with French FIRE 1 & Fault (FF) LEDs, non-EMC painted, with
Printed logo
VSP-200 Blank plate, EMC painted, without VESDA logo
VSP-540 Exhaust Deflector (black)
A.2 VESDA VLS
Part
number
Description
VSP-000 Blank plate, non-EMC painted, with VESDA logo
VSP-001 Programmer Module
VSP-004 Scanner Display Module
VSP-005 Filter Cartridge
VSP-009 VESDA VLSDetector Chassis Assembly complete with Manifold
l VSP-009: EN 54-20 compliant
l VSP-009-NEN: Non-EN 54-20 compliant
Note: Refer to Section 8.1.3 for further information.
VSP-013 Detector Cover Assembly complete with EMC shields
VSP-014 7-relay Head Termination Card (HTC7)
VSP-015 VESDA VLS Detector Aspirator Assembly
VSP-016 12-relay Head Termination Card (HTC12)
VSP-019 Filter Cover
VSP-021 Imperial Pipe Adaptors (25 mm to 27 mm) (4 off) (US only)
VSP-100 Blank plate with FIRE 1 & OK LEDs, non-EMC painted, with VESDA logo
