Vetek DGT - Page 44

DGT / DGT60 / DGTQ / DGTP
44
DGTQ model
A bit is ascribed to each input:
Expansion outputs
(optional)
Board
outputs
Bit not managed OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
Therefore if the OUTS0002D string is received, the hexadecimal value, converted into binary, indicates that the
status of the outputs is the following:
Expansion outputs
(optional)
Board
outputs
Bit not managed OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
Bit
15
0
Bit
14
0
Bit
13
0
Bit
12
0
Bit
11
0
Bit
10
0
Bit
9
0
Bit
8
0
Bit
7
0
Bit
6
0
Bit
5
1
Bit
4
0
Bit
3
1
Bit
2
1
Bit
1
0
Bit
0
1
The active outputs are therefore OUT 1, OUT 3, OUT 4 and OUT 6.
NOTES:
- The reading command of the outputs does not work in the set-up environment
- No output is ascribed to bits from 6 to 15 bits and these are fixed at zero.
DGTP model
A bit is ascribed to each input:
Board outputs
Bit not managed OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
Therefore if the OUTS0002D string is received, the hexadecimal value, converted into binary, indicates that the
status of the outputs is the following:
Board outputs
Bit not managed OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
Bit
15
0
Bit
14
0
Bit
13
0
Bit
12
0
Bit
11
0
Bit
10
0
Bit
9
0
Bit
8
0
Bit
7
0
Bit
6
0
Bit
5
1
Bit
4
0
Bit
3
1
Bit
2
1
Bit
1
0
Bit
0
1
The active outputs are therefore OUT 1, OUT 3, OUT 4 and OUT 6.
NOTES:
- The reading command of the outputs does not work in the set-up environment
- No output is ascribed to bits from 6 to 15 bits and these are fixed at zero.
