DGT / DGT60 / DGTQ / DGTP
46
Expansion outputs
(optional)
Board
outputs
Bit not managed OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
Bit
15
0
Bit
14
0
Bit
13
0
Bit
12
0
Bit
11
0
Bit
10
0
Bit
9
0
Bit
8
0
Bit
7
0
Bit
6
0
Bit
5
1
Bit
4
0
Bit
3
1
Bit
2
0
Bit
1
1
Bit
0
0
Which, in hexadecimals, corresponds to the number 002A; therefore the command will be OUTP0002A + CR + LF.
NOTES:
- The set point enabling command does not work neither in the set-up environment nor in the weighing phase; if the
setpoint mode has been selected and the output function is different than "nonE". (rif. output step, FunC parameter).
- No output is ascribed to the bits from 6 to 15 and are fixed at zero.
DGTP model
A bit is ascribed to each output:
Board outputs
Bit not managed OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
The bit at 1 is interpreted as active output, while the bit at 0 as disabled output.
If, for example, one wants to enable simultaneously the OUT6, OUT4 and OUT2 outputs, the binary combination will
be
Board outputs
Bit not managed OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
Bit
15
0
Bit
14
0
Bit
13
0
Bit
12
0
Bit
11
0
Bit
10
0
Bit
9
0
Bit
8
0
Bit
7
0
Bit
6
0
Bit
5
1
Bit
4
0
Bit
3
1
Bit
2
0
Bit
1
1
Bit
0
0
Which, in hexadecimals, corresponds to the number 002A; therefore the command will be OUTP0002A + CR + LF.
NOTES:
- The set point enabling command does not work neither in the set-up environment nor in the weighing phase; if the
setpoint mode has been selected and the output function is different than "nonE". (rif. output step, FunC parameter).
- No output is ascribed to the bits from 6 to 15 and are fixed at zero.
