VEVOR LB300A - Water Supply; Purge

Safety Tips
Number: JT190199990 Version Number: A1
Note: Subsequent versions of this specification are subject to change without prior notice. Thank you
5/23
Water supply/Purge
6. Water supply/ Purge
Warning
Ice makers shall be installed in
accordance with safety standards and shall
not be installed on the aisles of public
buildings.
6.1 Water supply

With local potable water quality,
determining if a water treatment system is
needed to prevent sediment formation,
filtering out impurities and removing
bleach smell .
 Please install water supply pipe according
to below instruction :

Don't connect ice maker to hot water
pipe；
 Water supply pressure range is 1bar～
5bar. Using water pressure regulator
for water supply pressure over rang.

Individual water faucet must be
installed for ice maker.
6.2 Purge

When installing drain hose, follow these
guidelines to be sure all purged water
flowing into gully drain：
 The main gully drain capacity shall be
enough for all drain water:
 Drain hose should be wrapped with
insulation material to prevent
condensation.

The drain hose of the water-cool
condenser and the drain hose of ice
bin should be placed separately
 About 2.5 centimeters drop needed
for each one meter additional drain
hose and must not be bent
