14
Pilot
Mounting holes (four locations) [P.16]
Output shaft
Motor cable [P.31,32]
Electromagnetic brake [motor with an electromagnetic brake] [P.32,41]
Non-excitation operation electromagnetic brake (24 VDC input)
Names and functions of parts
This section covers the names and functions of parts in the motor and driver.
For further details on each part, refer to the page shown in the square bracket.
Motor
Varistor
8F
5
C
‑
5
A
‑
3
An accessory supplied with the motor with an electromagnetic brake.
Be sure to connect the varistor when wiring the electromagnetic brake.
