Installation & User Manual
5 Technical data
5.1 Irradiation chamber
The VGE MultiMax UV system has an irradiation chamber with an inline design to create a compact design
that is easy to install in existing but also new water treatment installations.
Description
Specifications
Material
Stainless steel 316L
Maximum water pressure
10 bar
Finish, internal
RA 0,8 µm (except weld seam, optionally possible)
Finish, external
Glass bead blasted
Protection
IP54
Environment temperature, storage
+1 °C till +60 °C
Environment temperature, operation
+5 °C till +40 °C
Max. relative humidity
95 %, not condensing
Number of lamps
1
Lamp
400 W
Lamp connection
S.B.T. (Single-end Bayonet Technology)
Weight, dry
2 kg
Weight, wet
3 kg
Connection
2" male thread
Installation length
156 mm
5.2 Control panel
The UV system comes standard with a Compact controller for controlling the UV lamps, process monitoring
and the interface with the "outside world".
Description
Specifications
Material
Aluminium wall-mounted housing
Finish
Structure powder coating, RAL 7035
Protection
IP54
Ambient temperature, storage
-20 °C till +60 °C
Ambient temperature, operation
+5 °C till +40 °C
Max relative humidity
95 %, not condensing
Environment
Protected against direct sunlight and rain
Installation height
Max. 2,000 m
Supply voltage
1/N/PE 180-264 Vac 50/60 Hz
Power consumption
425 W
Working factor, cos φ
0,98
Dimensions (H x W x D)
460 x 250 x 150 mm
Weight
5 kg
