VGE MultiMax Pro - Spare Parts Sets

VGEM000-GB192
VGE International B.V.
●
Ekkersrijt 4304
●
5692 DH Son Netherlands
●
 +31 499 461099
●
info@vgebv.nl
●
www.vgebv.nl Pag. 63/68
Installation & User Manual
Item
Number
Art. number
Description
1
1
F980500
Lamp VGE Pro MP 400 W
2
2
F990898
Screw M4 x 40 mm A2 RVS DIN 912
3
1
3902150
O-ring 83 x 2.5 mm
4
1
F990303
MP lamp socket
5
1
F990068
MP lamp cable 18AWG SOW 2C 600 V/10 A 105 °C
6
1
3902170
Foam gasket EPDM clamping flange MP
7
6
F990899
Countersunk Allen screw M5 x 10 mm Stainless steel A2 DIN 7991
8
1
B212195
Clamping flange housing MP
9
1
B299616
Quartz tube locking MP 38 mm
10
1
3902172
Quartz tube protection ring EPDM 39 x 35 x 1 mm
11
1
QG100
Quartz tube 38 x 1.5 x 195 mm
12
1
3902174
O-ring EPDM 37.69 x 3.53 mm AS568-222
13
1
VIM00401H
Irradiation chamber VGE Pro MultiMax
15
1
4800040
Washer A2 M5
16
1
E831400
High cap nut M5 DIN 1587
17
1
B290146
Bimetallic switch 60 ºC incl. 10mtr cable
9.3 Spare parts sets
Service set:
This set consists out of the following parts:
- O-ring for lamp socket/socket;
- Foam gasket for socket/RVS flange;
- Quartz tube protection ring;
- O-ring for sealing quartz tube/SS flange;
- O-ring for UV sensor/SS plug;
- Screws for mounting clamping flanges.
The following parts are available:
- UV-lamp;
- Quartz tube.
UV-Lamp
This set consists out of the following parts:
- UV-lamp;
- O-ring for lamp socket/socket.
Quartz tube:
This set consists out of the following parts:
- Quartz tube;
- Service set.
Bimetallic switch:
This set consists out of the following parts:
- Bimetallic switch 60°C with 10 m cable;
- Cap nuts;
- Washers.
