VGE MultiMax Pro - 10 Drawings; Dimensions; Irradiation Chamber, Dimensions

VGEM000-GB192
VGE International B.V.
●
Ekkersrijt 4304
●
5692 DH Son Netherlands
●
 +31 499 461099
●
info@vgebv.nl
●
www.vgebv.nl Pag. 65/68
Installation & User Manual
10 Drawings
10.1 Dimensions
10.2 Irradiation chamber, dimensions
E
A
CD
G
B
F
H
J
Maximum
working
pressure
Connection
Weight
dry
Weight
wet
A B C D E F G H I J
[bar] [kg] [kg]
MultiMax
Inline 10 2" male 2 3 250 156 115 135 85 91 230 2" - 86
VGE Pro MD
Dimensions
Type
Shape
[mm]
