iMS3D – Operating Guide Document v2.12 5
Figure 7: System Charger
Figure 8: Embedded Tablet charger: this one should be
used when scanning
Figure 9: MOLEX connector to activate the battery
Figure 10: XLR connector used for chargers to be connected
to the processing unit
2 MOUNT YOUR SYSTEM
1. Open the boxes and start with the one which contains the kart
2. Put the roller frame on the floor
