72 OLP-87/OLP-87P
10 DATA MANAGEMENT
DATA MANAGEMENT OF PONMETER, XGPON AND BROADBAND TESTS
To show all columns of the overview:
J Press the right/left arrow keys to show additional information.
The displayed information depends on the selected
application.
Managing test results
To select/deselect a test result:
There are several ways to select and deselect test results:
1. Tap an entry once to highlight it, tap it again to select it.
2. Use the up/down arrows to highlight an entry and press the
center key to select it.
3. Press the
[A] key and tap the [Select All]button to select all.
4. Press the
[A] key and tap t h e [Deselect All] button to deselect
all.
NOTE: The selection state of the highlighted entry toggles. The check
mark in the first column shows in light grey when an entry is
deselected and in dark grey when it is selected.
To view test results in full screen:
I The measurement data overview is displayed.
1. Select one or more test results from the list.
2. Press the
[A] key and tap the [View Selected] button.
Measurement Data of ... Test ggf. Inhalte anpassen für PONmeter,
XGPON und Broadband?
Fiber ID Test label name
[nm] Wavelength
Pow [dBm]
measured Powermeter valuePow [Watt]
Pow [dB]
Ref [dBm] Reference value
Pass/Fail Passed/failed label
Limit [dBm] Limit value
Auto
optional Auto mode
Tone Ton e value
Timestamp Time and date of the test
