16
MISTRAL EVOLUTION
USER MANUAL
www.v icidbs.com
Version 1.03.0000
10.2. Alarms
Do stop the device.
ITEM DESCRIPTION
Temperature The temperature inside the cabinet is too high
Int. Tank Pressure Min. The pressure in the internal reservoir is too low
Int. Tank Pressure Max. The pressure in the internal reservoir is too high (10 bar) and the relief valve do
not work. Check the relief valve. The High pressure compressor may not work.
Call the service line.
P. Max Outlet The outlet pressure is too high. Check if the output tting is free. If it is all right,
call the service.
WT CMP The compressors must be changed.
SRV 4000 The lter must be changed. See service manual section on 4000 h service kit.
