4. SPECIFICATIONS
MISTRAL
EVOLUTION 10
MISTRAL
EVOLUTION 25
MISTRAL
EVOLUTION 35
MISTRAL
EVOLUTION 40
Nitrogen ow rate L/min 10 25 35 40
Nitrogen purity +99.5% 99% 98% 97%
Dewpoint
o
C (
o
F) -50 (-58)
Outlet pressure barg (psig) 3 (45) 8 (116)
Technology Carbon molecular sieve
Warm up time (minutes) 20
LED indicators Power on/off, system ready, errors
Electricity supply 110-120V 60Hz / 220-240V 50Hz
Power consumption (watts) 800 1800
Noise level 55 dBA @ 1 meter
Dimensions mm (in) 482W x 641H x 835D (18.9W x 25H x 33D)
Weight kg (lbs) 70 (155) 90 (198)
Shipping dimensions mm (in) 550W x 800H x 940D (21.6W x 31.4H x 37D)
Shipping weight kg (lbs) 95 (210) 115 (254)
Operating temp
o
C (
o
F) 15 to 35 (59 to 95)
Outlet connection 6 mm OD compression or 1/4”
Certication CE, FCC, MET (UL and CSA compliant)
MODELS & SPECS
OPERATING CONDITIONS
Environment Indoor
Temperature
o
C (
o
F) 10 to 40 (50 to 104)
Relative Humidity 0 to 80% rF with no condense / 0 to 99% rF with condense drain
Altitude <2000m (from 800 to 1150 hPa)
Instrument position Horizontal
Transient overvoltage Up to the levels of OVERVOLTAGE CATEGORY II
Heat dissipation Approximately 2700 Btu/h
Enclosure protection IP20
Mechanical impact rating IK08
Transient overvoltage <2500 kV (accept temporary overvoltage from power supply net)
