Operation
64
Balancing the cutting
unit
The balance of the machine's cutting unit should be adjusted so that
the downward pressure on the machine's cutting unit is about 40-60
kg (90-130 lb).
The balance of the cutting unit is adjusted in the following way:
Use an appropriate tool and loosen the counter nuts with the
springs on both sides of the machine.
Screw the bolt indicated.
• When the bolt is screwed clockwise the cutting unit's downward
pressure decreases.
• When the bolt is screwed clockwise the cutting unit's downward
pressure increases.
