iCNC XT
Manual 0-5299 INSTALLATION 3-13
Main gas connector XT231 ONLY
With the XT231 you can have separate outputs for each torch station and then select your active station with the Sel 1, Sel 2, Sel 3 switches on
the switch panel. You also have a main gas connector, the station select switches are ignored in these outputs.
By default the output connector will provide inlet voltage outputs.
Voltage selection jumpers explained on next page.
