iCNC XT
3-14 INSTALLATION Manual 0-5299
XT211
J3
Position Default Remarks
1-2 1-2 Inlet line voltage
2-3 User VCC
J4
Position Default Remarks
1-2 1-2 Inlet neutral voltage
2-3 User GND
