iCNC XT
Manual 0-5299 INSTALLATION 3-15
XT231
JP10
Position Default Remarks
1-2 1-2 Inlet line voltage
2-3 User VCC
JP11
Position Default Remarks
1-2 1-2 Inlet neutral voltage
2-3 User GND
JP12/JP13/JP14
Position Default Remarks
1-2 1-2 Inlet voltage lifter
2-3 User AC voltage lifter
