Victory BACKHOE Series - Specifications, Features, Performance

Operator’s Manual Backhoe Series BH - Page 87 of 91 - Version 2.0
11 SPECIFICATIONS, FEATURES, PERFORMANCE
Specifications:
Technical Specifications
BH-6
BH-7
BH-8
Dimensions (H x W x D)
(mounted on tractor)
68 x 51 x 48 inch
71 x 51 x 48 inch
78 x 51 x 55 inch
Total Weight:
994 lb.
1,080 lb.
1,325 lb.
3-point hitch:
CAT I/II
Max. PTO shaft rpm recommended:
540 rpm
PTO shaft spline:
1 3/8″
Drive System:
PTO Driven Hydr. Gear pump
Hydraulic Tank (with site glass):
17 ltr./4.3 Gal.
Max. Pump Performance:
22 ltr./min. at 2250 psi
Pump Gearbox oil:
4 oz of 85/90 W Gear oil.
Tractor Engine Power-recommended:
18 -35 hp
25 -55 hp
40 -75 hp
Bucket size:
2 Rippers
3 Rippers
4 Rippers
Bucket width:
9 in.
12 in.
15 in.
Other Buckets available:
(Thumb is an optional part)
9″, 18″ & Thumb
9″, 18″ & Thumb
9″, 18″ & Thumb
Max. working depth:
6 ft.
7 ft.
8 ft.
Max. working radius:
102 in.
116 in.
126 in.
Max. height:
108 in.
122 in.
138 in.
Max. off-loading height:
63 in.
70 in.
75 in.
Max. lifted weight:
880 lb.
Max. bucket digging force:
3,300 lb.
Painting:
Black; Powder coated
Steel crate dimensions:
220 x 90 x 110 cm
Backhoe turning angle:
180 Degrees
Bucket rotation:
172 Degrees
Hydraulic stabilizer width:
- Up position:
1186 mm.
- Down position:
2173 mm
Features:
◼ Safety valves for all control circuits.
◼ Hydraulic hoses with safety covers.
◼ New generation hydraulic cylinders for smooth performance.
◼ Bushings for arms and feet for easy service exchangeable.
◼ Your choice in bucket size 9″, 12″, 15″, or 18″ (Thumb as an option available).
Performance BH6:
◼ The tractor’s PTO output shaft drives the 2250 psi Victory hydraulic gear pump for the
Backhoe’s hydraulic system (no need for tractor hydraulics).
◼ Because of the weight of the BH-6 (994 lbs.), you should use extra weights when excavating on
lighter tractors. Please consult with your tractor’s manufacturer.
◼ The BH-6 can stay mounted on your tractor when driving on public roads. It does not cover any
of your tractor’s lights.
