Victron energy BlueSolar MPPT 150/35 User Manual

Example of a VE.Smart Network of a Smart Battery Sense and a solar charger.
3.11. Voltage sensing
An optional Smart Battery Sense or battery monitor measures the battery terminal voltage and sends this via Bluetooth using the
VE.Smart [29] network to the solar charger. If the battery voltage is less than the solar charge voltage, the solar charger will
increase its charge voltage to compensate for voltage losses.
3.12. Remote on/off
A virtual remote on/off terminal can be created by using the (optional) VE.Direct non inverting remote on/off cable.
3.13. WireBox
The optional MPPT WireBox is a plastic cover that can be attached to the bottom of the solar charger. It covers the battery and
solar terminals, preventing accidental or inquisitive contact with the battery and PV terminals. It provides an extra level of safety,
and is particularly useful if the solar charger is installed in a general access area.
For more information and to find the right MPPT WireBox for your solar charger see the MPPT WireBox product page:
• MPPT WireBox-Tr
Example of a solar charger with MPPT WireBox
MPPT solar charger manual
Page 9 Features

Victron energy BlueSolar MPPT 150/35 Specifications

General

Model	BlueSolar MPPT 150/35
Category	Controller
Maximum PV open circuit voltage	150 V
Maximum output current	35 A
Efficiency	98%
Protection category	IP22
Humidity	95%, non-condensing
Battery voltage	12/24/48V
Self consumption	10mA
Operating temperature	-30°C to +60°C
Bluetooth compatibility	Yes, via optional VE.Direct Bluetooth Smart dongle
Protection	Short circuit, reverse polarity
